8.16 USER SETTINGS
8.16.2.2 DIFFERENTIAL CURRENT UNITS GROUP 2
GROUP 2 FIRST LEVEL
DIFFERENTIAL
FUNCTION
First Level 87 Enable
Permission to Trip First
Level 87
First Level 87 Tap / Pickup
Value
First Level 87 Definite
Time Delay
GROUP 2 SECOND
LEVEL DIFFERENTIAL
FUNCTION
Second Level 87 Enable
Permission to Trip Second
Level 87
Second Level 87 Tap /
Pickup Value
Second Level 87 Definite
Time Delay
8.16.2.3 EVENT MASK
8
8-18
ENERVISTA MIIPC
87 1 FUNCTION GROUP2
87 1 G2 Enable ENABLE 87 1 G2
87 1 G2 Trip Enable TRIP 87 1 G2
87 1 G2 Pickup Level TAP 87 1 G2
87 1 G2 Time Delay TIME 87 1 G2
87 2 FUNCTION GROUP2
87 2 G2 Enable ENABLE 87 2 G2
87 2 G2 Trip Enable TRIP 87 2 G2
87 2 G2 Pickup Level TAP 87 2 G2
87 2 G2 Time Delay TIME 87 2 G2
MIB High Impedance Bus Differntial Relay
HMI USER VALUE
F87 1 G2
F87 2 G2
8 RELAY COMMISSIONING
RANGE STEP
Y/N NA
Y/N NA
0.005-0.04 A 0.01 A
0 – 600.00 s. 0.01 s.
Y/N NA
Y/N NA
0.005-0.04 A 0.01 A
0 – 600.00 s. 0.01 s.
