A.2 COMMAND EXECUTION
A.2.2.1 SELECTION
Request:
To activate Group 2, the selection command will be 0FH; therefore the operation to be performed is a writing of word 0F
00H at the address 00 00H.
Request:
ADDRESS
01H
A
Reply:
ADDRESS
01H
A.2.2.2 CONFIRMATION
The operation confirmation code for Group 2 activation is 16 (10h). In this case, it is necessary to send the
relay password (in this example its value is 1)
Request:
ADDRESS
01H
Reply:
ADDRESS
01H
A-6
FUNCTION BEGINNING
10H 0000H
FUNCTION
10H
FUNCTION BEGINNING
10H 0000H
FUNCTION
10H
MIB High Impedance Bus Differntial Relay
#REGS #BYTES
0001H 02H
BEGINNING #REGS
0000H 0001H
#REGS #BYTES DATA0
0003H 06H 10 00H
BEGINNING #REGS
0000H 0003H
APPENDIX A
A.2.2 EXAMPLE
DATA0 CRC
0F00H A3A0H
CRC
01C9H
DATA1 DATA2 CRC
01 00H 00 00H E5ECH
CRC
8008H
