B.3 SAMPLES OF SETTINGS FOR PARTICULAR MODEMS
In this case, the modem initial configuration is set by changing the microswitches located in three sets on the bottom of
the units.
Location of modem microswitches on the PC side:
Set 1
Nº DESCRIPTIÓN
1 112 ETD/OFF
ON: Circuit 112 connected to ETD
OFF: Circuit 112 connected to ETD
2 112 ETD/ON
ON: 108 circuit forced to CLOSED.
OFF: 108 circuit follows ETD's 108 circuit
3 105 ETD/ON
ON: Circuit 105 forced to CLOSED.
OFF: Circuit 105 follows ETD's 105circuit
4 TXA/TXB in a peer-to-peer line (PP)
ON: In PP transfers through high channel.
OFF: In PP transfers through low channel.
5&6 Baud ate selection for data transfer
ON-ON1200
OFF-ON2400
ON-OFFAutomatic.
OFF-OFFAutomatic.
7&8 Automatic disconnection.
ON-ONNo automatic disconnection.
OFF-ONCircuit 105.
ON-OFFCircuit 109.
OFF-OFFCircuits 105 and 109.
Set 2
B
NO. DESCRIPTION
1 Synchronous format of protocol V25bis in option 108.2.
ON: Character oriented format (BSC).
OFF: Bit oriented format (HDLC).
2&3 Asynchronous character format for data transfer
ON-ON8
OFF-ON9
ON-OFF10
OFF-OFF11
4 Reception permission for remote loop 2
ON: Not permitted.
OFF: Permitted.
5&6 Exploitation mode.
ON-ONPoint-to-point line
OFF-ONAutomatic call as per 108.1.
ON-OFFRTC line without automatic call.
OFF-OFFAutomatic call as per 108.2.
7 Number of calls for automatic answer
ON: 1 call.
OFF: 2 calls.
8 112 ETD/OFF
ON: Asynchronous operation.
OFF: Synchronous operation.
