2.10 TECHNICAL SPECIFICATIONS.
Max. Ratings for 100.000 operations:
VOLTAGE
DC Resistive
24 Vdc
48 Vdc
2
125 Vdc
250 Vdc
AC Resistive
120 Vac
250 Vac
AC Inductive
PF = 0.4
250 Vac
FRONT PORT
REAR PORT
Operating Temperatures:
Ambient Storage Temperatures:
Maximum relative humidity
Altitude
Pollution Degree
2-20
MAKE&CARRY
MAKE&CARRY 0.2 SEC
CONTINUOUS
16 A
16 A
16 A
16 A
16 A
16 A
10 A
RS232
RS485
-20º C to +60º C
-40º C to +80º C
95%
2000 m. Max
2
MIB High Impedance Bus Differntial Relay
BREAK
48 A 16 A
48 A 2.6 A
48 A 0.6 A
48 A 0.5 A
48 A 16 A
48 A 16 A
30 A 10 A
300, 600, 1200, 2400, 4800, 9600 or 19200 bps,
Modbus® RTU
300, 600, 1200, 2400, 4800, 9600 or 19200 bps,
Modbus® RTU
2 PRODUCT DESCRIPTION
MAX LOAD
384W
125W
75 W
125 W
1920 VA
4000 VA
1000 VA

2.10.6 COMMUNICATIONS

2.10.7 ENVIRONMENTAL
