APPENDIX A
A.5.1.3 EVENTS READING
Request:
Reply:
A.5.1.4 EVENTS CLOSING
Request:
FIELD
Relay address
Function
Initiation address
No of registers
No of bytes
Value of registers
CRC
Reply:
FIELD
Relay address
Function
Initiation address
No of registers
CRC
GEK-106426B
FIELD LENGTH
Relay address 1 Byte
Function 1 Byte (03H)
Initiation address 1 Word (High byte – Low byte)
No of registers 1 Word (High byte – Low byte)
CRC 1 Word
FIELD LENGTH
Relay address 1 Byte
Function 1 Byte (03H)
No of bytes 1 Byte
Value of registers No of bytes/2 words (High byte – Low byte)
CRC 1 Word
LENGTH
1 Byte
1 Byte (10H)
1 Word (0000H) (High byte – Low byte)
1 Word (0004H) (High byte – Low byte)
1 Byte (08H)
4 Words:
Register1=> Command code (1400H) (Low byte – High byte)
Registers 2 & 3=> Relay password (Byte 3 – byte 2 – byte 1 – byte 0)
Register4=> VALUE (Low byte – High byte).
1 Word
LENGTH
1 Byte
1 Byte (10H)
1 Word (0000H) (High byte – Low byte)
1 Word (0004H) (High byte – Low byte)
1 Word
MIB High Impedance Bus Differntial Relay
A.5 EVENTS
A
