5 SETTINGS
OSCILLOGRAPHY MASK
Oscillography Trigger by communications
Oscillography Trigger by digital input
Oscillography Trigger by tripping
Oscillography Trigger by pickup
GEK-106426B
ENERVISTA MII SETUP
Oscillo by communic.
Oscillo by digital input
Oscillo by tripping
Oscillo by pickup
MIB High Impedance Bus Differntial Relay
5.3 ADVANCED SETTINGS
5.3.7 OSCILLOGRAPHY MASKS
DEFAULT
RANGE
STEP
NO
Y/N
NA
NO
Y/N
NA
NO
Y/N
NA
NO
Y/N
NA
5
5-7
