APPENDIX A
This example modifies the IDENTIFICATION setting of an MIB module that stores this information at position 0134H of its
memory map. The module identification in an ASCII text of 16 characters.
SELECTION:
Request:
ADDRESS FUNCTION
01H 10H
Reply:
ADDRESS
01H
SETTING CHANGE
Request:
ADDRESS
01H
ADDRESS
01
DATA0 DATA1 DATA2
5445 5356H 494E
Data0 => 5445 ("T""E")
Data1 => 5354 ("S""T")
Data2 => 494E ("I""N")
Data3 => 4700 ("G"-00) (00 = End of string
Reply:
ADDRESS
01
GEK-106426B
BEGINNING #REGS
0000H 0001H
FUNCTION BEGINNING
10H 0000H
FUNCTION BEGINNING
10H 0128H
FUNCTION BEGINNING
10 0134
DATA3 DATA4
4700 0000
Data4 => 00xx (00 = End of the chain. The remaining characters are
not considered
Data5 => xxxx
Data6 => xxxx
Data7 => xxxx
FUNCTION BEGINNING
10 0118
MIB High Impedance Bus Differntial Relay
A.4 WRITING SETTINGS
A.4.3 EXAMPLE OF SETTING CHANGE
BYTES DATA0
02H 0100H
#REGS CRC
0001H 01C9H
#REGS #BYTES
0008H 10H
#REGS #BYTES
0008 10
DATA5 DATA6 DATA7
0000 0000 0000
#REGS CRC
0008 4034
CRC
A7C0H
A
CRC
5361
A-11
