3 HARDWARE 3.2 HIGH IMPEDANCE MODULE DESCRIPTION

3.2.3 REAR DESCRIPTION

The relay is wired through the terminal blocks located at the rear of the unit. The maximum recommended cable section
2
for this terminal board, with the appropriate terminal, is 6 mm (AWG 10).
3
Figure 3–4: REAR TERMINALS DIAGRAM
GEK-106426B MIB High Impedance Bus Differntial Relay 3-5
