Inner Gas Nozzle Cleaning Brush Program Sequence - Fronius Robacta TSS /i Operating Instructions Manual

Inner gas nozzle
Move to position F
cleaning brush
approx. 50 mm/1.97 in. centrally above
program
the inner gas nozzle cleaning brush
sequence
Contact tip 1 vertical to the service sta-
tion
Speed: High-speed mode
Set
external signal "Internal valve brush
cleaning"
Move into the inner gas nozzle clean-
ing brush
max. speed: 50 cm/min / 19.69 ipm
max. insertion depth: 1/3 of the brush
length
Move to position F
approx. 50 mm/1.97 in. centrally above
the inner gas nozzle cleaning brush
Contact tip 2 vertical to the service sta-
tion
max. speed: 50 cm/min (19.69 ipm)
Move into the inner gas nozzle clean-
ing brush
max. speed: 50 cm/min / 19.69 ipm
max. insertion depth: 1/3 of the brush
length
Move to position F
approx. 50 mm/1.97 in. centrally above
the inner gas nozzle cleaning brush
Contact tip 2 vertical to the service sta-
tion
max. speed: 50 cm/min (19.69 ipm)
78
1
Wait 2-3 seconds
2
Wait 2-3 seconds
F
50 mm
1.97 in.
