Fronius Robacta TSS /i Operating Instructions Manual page 43

*
1 8
1 7
1 8
1 8
Position cover
17
Install cover using 6 TX25 screws
18
Apply cable lug of an additional cable
19
1 8
to the screw protruding out of the
housing and use the serrated washer
and 8 mm hexagonal nut from the
1 8
scope of supply to secure the OPT/i
6x
TSS TCP Touch Sense
TX25
Use the additional cable to establish a
20
connection to the workpiece/ground
1 8
43
