Fronius Robacta TSS /i Operating Instructions Manual page 23

(21)
(20)
(19)
(18)
View B
(17) Compressed air connection
Nominal pressure 6 bar
(18) Compressed air connection
Nominal pressure 6 bar
(19) Compressed air connection
Nominal pressure 6 bar
(20) Parting agent connection
(21) Compressed air connection
Gas purging through hosepack, 16 bar
(11) External optional equipment
connection
(12) External optional equipment
connection
(11)
(13) External optional equipment
(12)
(13) connection
(14)
(14) External optional equipment
(15)
connection
(16)
(17)
The 37-pin connections (11)–(14) for
external optional equipment are equal.
(15) Compressed air connection
Nominal pressure 6 bar
(16) Compressed air connection
Nominal pressure 6 bar
23
