Fronius Robacta TSS /i Operating Instructions Manual page 55

9
9
1 0
1 1
1 2
1 3
1 3
1 3
Carry out the commissioning of the level sensor in accordance with the "Commissioning
level sensor" instructions (42,0410,2553).
The instructions are included in the scope of delivery of the level sensor.
Guide the sensor cable through the
8
recess to the other side
Attach the sensor cable to the avail-
9
able cable piece
8
Close flap for parting agent container
10
1 2
IMPORTANT! When inserting the frame,
ensure that the metal strap is positioned in
the recess.
Insert the frame
11
Lift up the frame
12
Use three TX25 screws to secure the
13
frame on the right
1 5
Use three TX25 screws to secure the
14
frame on the left
Pull spring pins and insert collecting
15
tray
1 4
1 4
1 4
55
