Technical data

General
Net weight
Device dimensions
Flammability class of housing
Battery
Transport and storage
The following details are valid for devices that are transported or stored in the original packag-
ing.
Drop test
Temperature
Environmental conditions in operation
The UMG511 is suitable for installation in stationary and weather-protected applications.
The UMG511 must be connected with the terminal earth connection!
Working temperature range
Relative humidity
Degree of pollution
Operating height
Installation position
Ventilation
Foreign particles and water protection,
Front
Front with seal (option)
Back
Technical data
: 1080g
: approx. l=144mm, w=144mm, h=75mm
: UL 94V-0
: TypeVARTA CR1/2AA, 3 V, Li-Mn
: 1m
: -20°C to +70°C
: -10°C .. +55°C
: 5 to 95 %, (at +25 °C) without condensation
: 2
: 0 .. 2000m above sea level
: user-defined
: external ventilation is not required.
: IP50 according to EN60529
: IP54 according to EN60529
: IP20 according to EN60529
