Inputs and outputs
8 digital inputs
Maximum counting frequency
Reaction time (Jasic programme)
Input signal is applied
Input signal is not applied
5 digital outputs, semi conductor relay, not short-circuited.
Switching voltage
Switching current
Reaction time (Jasic programme)
Issue of voltage dips
Issue of voltage excesses
Impulse output (working impulse)
Cable length
Connection capacity of clamping points
Rigid/flexible
Flexible with wire end ferrules without plastic sleeves : 0.25 - 1.5mm 2
Flexible with wire end ferrules with plastic sleeves
Torque
Strip length
Technical data
: 20Hz
: 200ms
: 18V .. 28V DC (typical 4mA)
: 0 .. 5V DC, current lower than 0.5mA
: max. 60V DC, 30V AC
: max. 50mAeff AC/DC
: 200ms
: 20ms
: 20ms
: max. 20Hz
: up to 30m not shielded
: larger than 30m shielded
: 0.14 - 1.5mm 2 , AWG 28-16
: 0.25 - 0.5mm 2
: 0.22 - 0.25Nm
: 7mm
