Current measurement

Nominal current

Measurement current

Resolution

Crest factor

Overvoltage category

Measurement surge voltage

Power consumption

Overload for 1 second

Scanning frequency

Connectable cables (current measurement and voltage measurement). Only one cable per clamp

may be connected!

Single wire, multi-wire, fine wire

Pin cable lugs, wire end ferrules

Torque

Strip length

Technical data

: 5A

: 6A

: 0,1mA

: 2 (relating to 6Arms)

: 300V CAT III

: 4kV

: ca. 0.2 VA, (Ri=5mOhm)

: 60A (sinusoidal)

: 20kHz

: 0.2 - 2.5mm 2 , AWG 24 - 12

: 0.25 - 2.5mm 2

: 0.5 - 0.6Nm

: 7mm
