Supply voltage
The supply voltage must be connected to the UMG511 using a UL listed circuit breaker or a G
fuse link. With the use of G fuse links, the fuse holder must also be UL listed.
Installation overvoltage category
Circuit breaker
Option 230V
Nominal range
Working range
Power consumption
Option 90V
Nominal range
Working range
Power consumption
Option 90V
Nominal range
Working range
Power consumption
Connectable cables
Only one cable per clamp may be connected!
Single wire, multi-wire, fine wire
Wire end ferrules with
and without plastic sleeves
Strip length
Torque
Protection class
Protection class I according to IEC 60536 (VDE 0106, part 1) i.e. an earth cable connection is
necessary!
Foreign particles and water protection
66
Technical data
: II
: 6A tripping characteristic B
: 95V .. 240V (45-65Hz) or DC 135V .. 340V
: +-10% of nominal range
: max. 10W, max. 15VA
: 44V .. 130V (45-65Hz) or DC 48V .. 180V
: +-10% of nominal range
: max. 10W, max. 15VA
: 20V .. 50V (45-65Hz) or DC 20V .. 70V
: +-10% of nominal range
: max. 10W, max. 15VA
: 0.2 - 2.5mm2, AWG 24 - 12
: 0.25 - 2.5mm2
: 7mm
: 0.5 - 0.6Nm
: IP20 according to EN60529 September 2000,
IEC60529:1989
