Scope of supply
Number Art. no.
1 52 19 xxx 1)
1 33 03 089
1 51 00 116
1 10 01 601
1 10 01 653
1 10 01 674
1 10 01 952
2 10 01 769
1 08 01 504
1 08 01 505
1 52 19 301
1) Article number - see delivery note
Available accessories
Art. no.
13 10 539
29 01 903
Goods-in check
Designation
UMG511
Installation and commissioning instructions.
CD with the following contents:
- Programming "GridVis" software,
- Functional descriptions, GridVis, UMG511,
- UMG511, GSD file "U5110C2B.GSD" for Profibus DP V0.
screw clamp, pluggable, 2 pin (auxiliary energy).
screw clamp, pluggable, 5 pin (voltage measurement 1-4).
screw clamp, pluggable, 8 pin (current measurement 1-4).
screw clamp, pluggable, 6 pin (digital outputs).
screw clamp, pluggable, 5 pin (digital inputs).
patch cable 3m, blue. (connection UMG - switch/hub)
patch cable 2m, twisted, (connection UMG - PC)
fixing clamps
Designation
Profibus plug, 9-pin DSUB, with integrated switchable
terminating resistors.
Sealing, 144x144.
