N100 INSTRUCTION MANUAL

9. Operating the inverter

9.1 Identifying the parts

RUN LED
on when the inverter
outputs the PWM
voltage and operating
command is ready
POWER LED
On when the control
powerinput to inverter
is on
Display part (LED display)
This part display frequency,
motor current, motor
rotation speed, alarm history,
and setting value.
RUN key
Press this key to run the
motor. The Run enable
LED must be terminal
operation
FUNCTION key
This key is used for
changing parameter
and command

9.2 Operation procedure

(Example that the frequency is set from potentiometer to the standard operator and the
equipment starts running)
STR
RUN
press the key
Oper-
ation
start
STOP/RESET key
This key is use for stopping the motor or resetting
errors. (When either operator or terminal is selected,
this key works. If the extension function b 15 is used,
this function is void)
Display after
power is
FUNC
turned on
press the key
once
store the
set the frequency
data
to 60Hz
0.0
060.0
Motor
Operation
F 01 F 01
press the key
9 times
0.0
UP/ DOWN key
This key is used to
change data and
increase of decrease
the frequency.
press the key
once
01 A -- A --
press the key
four times
chage the frequency
command by key
operation from the
potentiometer
A--
F 01 F 01
FUNC
press the key
press the key
once
four times
01
60.0
FUNC
press the key
once
PRG LED
This LED is on when the
inverter is ready for
parameter editing.
Hz/A LED
Display units Hertz/Ampere
LEDs.
Potentiometer
set the inverter output
frequency.(be operated
only when the ramp is
ON)
STORE KEY
Press the store key to write the
data and setting value to the
memory
FUNC
A 01 A 01
FUNC
0
press the key twice
STR
store the data
A 01 A 01
FUNC
display transition
frequency monitor
Hz
