N100 INSTRUCTION MANUAL

Software Lock[SFT]

When the terminal [SFT] is turned on, the data of all the parameters and
functions except the output frequency is locked (prohibited from editing).
When the data is locked, the keypad keys cannot edit inverter parameters.
To edit parameters again, turn off the [SFT] terminal input.
Use parameter B31 to select whether the output frequency is excluded from the
lock state or is locked as well.
Terminal
Option
Symbol
Code
SFT
15
Valid for inputs:
Required setting
Notes:
When the [SFT] terminal is turned on,
only the output frequency can be
changed.
Software lock can be made possible also
for the output frequency by b09
Software lock by the operator is also
possible without [SFT] terminal being
used (b09)
Function Name
Software Lock
C01,C02,C03,C04,C05,C06
B09 (excluded from lock)
Input
State
The keypad and remote program-
ming devices are prevented from
ON
changing parameters
The parameters may be edited
OFF
and stored
Example:
6
CM1
Description
SFT FW
5 4 3 2 1 P24
