3 Using the Module
Install the Optional Integrated Column Compartment
3 Loosen the Quick Turn Fitting either with your fingers or
with the help of two wrenches.
5 Lift up the lever to release the tension on the Quick Con-
nect Fitting.
7 Remove the column from the ICC.
Agilent InfinityLab LC Series Vialsamplers User Manual
4 Remove the capillary from the outlet port of the column.
6 Unscrew and remove the Quick Connect Fitting.
8 Close the flap door until the latch is locked.
Click
