Agilent Technologies InfinityLab LC Series User Manual page 298

9 Parts and Materials for Maintenance
2 Position/6 Port Injection Valve, 600 bar
2 Position/6 Port Injection Valve, 600 bar
Item
1
2
3
4
5
Figure 48
Agilent InfinityLab LC Series Vialsamplers User Manual
p/n Description
5067-4245 2 Position/6 Port Injection Valve, 600 bar
5068-0018 Screws, ST, 8-32, Hex 9/64, 10/pk
5068-0215 Stator, Injection Valve, 600 bar/800 bar
5068-0118 Stator ring
0101-1416 Rotor Seal, PEEK, 600/800 bar
1535-4045 Bearing ring
3
2
1
2 Position/6 Port Injection Valve 600 bar/800 bar
5
4
298
