10 Identifying Cables
Remote Cables
•
Table 22 5188-8057 ERI to APG and RJ45
p/n 5188-8057
One end of these cables provides a Agilent Technologies APG (Analytical
Products Group) remote connector to be connected to Agilent modules. The
other end depends on the instrument to be connected to.
Agilent InfinityLab LC Series Vialsamplers User Manual
5188-8057 ERI to APG and RJ45 (Connector D_Subminiature 15 pin (ERI),
Connector D_Subminiature 9 pin (APG), Connector plug Cat5e (RJ45))
Pin (ERI)
10
1
2
3
4
5
6
7
8
Ground
Signal Pin (APG)
GND 1
Start 9
Request
Stop 8
Ready 7
Fraction Trig- 5
ger
Power on 6
Shut Down 4
Start 3
Prepare 2
Cable Shield- NC
ing
Active (TTL) Pin (RJ45)
5
High
High
High
High 4
High
High
High
High
