RS 660 - Tuono 660
•
Insert the impeller (5) and tighten it to
the prescribed torque.

Removing the radiator

To remove the radiator it is necessary to remove
the side and lower fairings. Then proceed as de-
scribed:
•
Remove the expansion tank cap (1).
•
Remove the radiator cap (2).
•
Operating on the left side of the motor-
cycle, remove the screw (3) to com-
pletely drain the cooling system, taking
care to collect the metal washer.
Cooling system
COOL SYS - 371
