APRILIA Tuono 660 2021 Service Station Manual page 386

Bodywork
•
Slide the light switch (14) off the semi-
handlebar to remove it completely.
Driving mirrors
Depending on the target market, the rear-view mirrors can be equipped with integrated arrows, therefore
before proceeding with the removal it is necessary to disconnect the connectors from the fixed con-
nectors on the instrument cluster support.
Then proceed as described:
THE FOLLOWING OPERATIONS REFER TO A
SINGLE REAR-VIEW MIRROR, BUT APPLY TO
BOTH.
•
Remove the two rear-view mirror lock
nuts.
•
Remove the rear-view mirror and, if ap-
plicable, slide the arrow wiring off the
fairing.
BODYW - 386
RS 660 - Tuono 660
