Engine

Chain removal

To proceed with the removal of the timing chain,
proceed as described:
•
Remove the chain from the timing gear
on the crankshaft.
•
Remove the chain from the head.
Removing the chain sliders
To proceed with the removal of the slider, it is nec-
essary to remove the complete head and then
proceed as described:
•
Remove the fixed slider (1) from its
seat in the crankcase.
•
Remove the fixing screw (2) of the mo-
bile slider.
