Braking system
•
Remove the three plastic cable grom-
mets (10) and the rubber cable grom-
met (11) to release the brake hose from
the ABS sensor wiring.
•
Remove the two screws (12) fastening
the rear brake calliper.
•
Extract the rear brake calliper (13) re-
leasing the brake hose from the cable
grommet (14).
•
Unscrew the two screws (15) and re-
move the closing bracket (16) of the
radiator support which holds the front
brake hoses.
