Braking system
Installing
After checking the integrity and the state of wear
of the brake disc, if it is not replaced with a new
disc, proceed as described to carry out the fitting:
•
Position the brake disc (1) on the rim,
making sure it is in the correct direction
of installation.
WARNING
THE FLAT SURFACE MUST SUPPORT THE RIM WHILE
THE UNLOADED AND PAINTED SURFACE MUST BE FAC-
ING OUTSIDE.
•
Position the tone wheel (2) on the rim,
making sure it is in the correct direction
of installation.
WARNING
THE CURVED SURFACE ON THE INSIDE MUST BE FACED
OUTSIDE AS INDICATED.
•
Insert the five screws (3) and tighten
them to the specified torque in the in-
dicated order (A-B-C-D-E).
