14 Overview
•
MG 1000E Chassis (NTDU14) and Expansion Chassis (NTDU15)
•
Media Gateway 1010 (MG 1010) (NTC310)
In this document, the following hardware is referred to generically as
Server:
•
Common Processor Pentium Mobile (CP PM) card
•
Common Processor Media Gateway (CP MG) card
•
Common Processor Dual Core (CP DC) card
•
Commercial off-the-shelf (COTS) servers
—
—
—
—
In this document, the generic term COTS refers to all COTS servers. The
term COTS1 or COTS2 refers to the specific servers in the preceding list.
In this document, the following hardware is referred to as Gateway
Controller:
•
Media Gateway Controller (MGC) card (NTDW60 and NTDW98)
•
Common Processor Media Gateway (CP MG) card (NTDW56 and
NTDW59)
•
Media Gateway Extended Peripheral Equipment Controller (MG XPEC)
card
Note:
maintenance commands are supported on all Gateway Controller
platforms unless otherwise indicated.
Co-res CS and SS is not supported on COTS1 servers. You can deploy a
COTS1 server as a stand-alone Signaling Server.
The following table shows CS 1000 Release 7.0 supported roles for
hardware platforms.
Table 1
Hardware platform supported roles
Hardware VxWorks Server
platform
yes
CP PIV
IBM x306m server (COTS1)
HP DL320 G4 server (COTS1)
IBM x3350 server (COTS2)
Dell R300 server (COTS2)
Gateway Controllers run a common MGC loadware. The MGC
Linux Server
no
Nortel Communication Server 1000
Communication Server 1000E Maintenance
NN43041-700 04.01 4 June 2010
Copyright © 2004-2010 Nortel Networks. All Rights Reserved.
Co-res CS and Gateway
SS Controller
no no
