168 Media Card maintenance
For additional information on the output format of the IDU command in LD
32 and the maintenance commands in LD 32 for the IP Phone, see IP Line
Fundamentals.
Lamp Audit
The Lamp Audit function provides a continuous source of heartbeat
messages to ensure the IP Phone is powered and the IP connection is
active. Because there is a reliable UDP connection from the Call Server
to the IP Phones, any failure in the IP Phones, or the IP connections is
detected. In addition to Lamp Audit, Network Signaling Diagnostics can be
run as part of the midnight routines.

IP line shell commands

The IP Line shell commands are designed to supplement overlay
commands and to manage features specific to the IP Line platform.
The IP Line shell commands are accessed by connecting a TTY to the
MAINT port on the Media Card faceplate.
Commands are grouped into six categories:
•
General purpose commands
•
File transfer commands
•
IP configuration commands
•
Reset commands
•
DSP commands
To view a list of the ITG shell commands applicable to the Media Card see
IP Line Fundamentals.
Warm rebooting the Media Card
To warm reboot an out-of-service Media Card, use the following IP Line
shell command:
cardReset
Media Card DSP tests
At the IP Line shell, you can perform the following DSP tests:
•
To run a self-test on the DSP daughterboard, type
DSPselfTest
If the self-test fails, replace the Media Card.
•
To run or stop a PCM loopback test, type
DSPPcmLpbkTestOn or DSPPcmLpbkTestOff
