Table 23
Call Server faults
Condition
Software Installation
Tool does not load
Data dump error,
or no access
to overlays and
OVL005 message
is displayed
System Utility card
LED is red and no
TTY output on Com
1
System constantly
rebooting
System Utility card
LED is red and TTY
output on Com 1
Defective RMD
FMD not responding
Ethernet port LEDs
are off
Ethernet ports unabl
e to communicate
Possible cause
Mismatch between the
Security Device and
keycode
Incorrect Install Program
disk
Manual initialize button
pressed during a backup
that uses the Customer
Configuration Backup
and Restore feature
Defective CP card
Defective System Utility
card
Defective CF card
Defective or
unprogrammed CF card
Bad cable or cable not
connected
Autonegotiation failed
Nortel Communication Server 1000
Communication Server 1000E Maintenance
NN43041-700 04.01 4 June 2010
Copyright © 2004-2010 Nortel Networks. All Rights Reserved.
Clearing Core Call Server faults 77
Action
Positively identify the eight digits engraved on
the face of the Security Device beneath the
Nortel logo (NT SDID) with the NT SDID on the
keycode floppy disk label, and verify the NT
SDIDs match.
Verify that you are using the correct Install
Program disk for your system.
Issue the ENLT command at the TTY.
Unseat the CP card and reinstall it. Make sure
all cables are securely connected. If the fault
remains, continue with this step.
Replace the cable to the Com 1 port. If the fault
remains, replace the CP PIV card.
If the CP card is replaced and the symptoms
persist, replace the Call Server.
Ensure the Enable/Disable switch is in the
enabled position. If the LED remains red, test
the card by entering
LD 135
TEST SUTL C 15
C represents the affected Call Server, either 0
or 1.
If the fault remains, replace the System Utility
card.
Stat RMD in LD 135 to obtain partition status.
Repartition if partition is corrupt or unreadable,
or replace the CF card.
Reinstall software or replace FMD.
Test cable, replace cable if necessary, and
make sure all equipment power is on.
Check configuration of LAN equipment (must be
set to autonegotiate).
