Replacing the NT5K21 equipment card

Procedure 37
Replacing the NT5K21 XMFC/MFE equipment card
Step
1
2
3
4
Unhook the locking devices on the card. Pull it out of the card
cage.
On the replacement card, configure option switches or jumper
plugs to the same settings as those on the card you removed.
Insert the replacement card into the vacated slot and hook the
locking devices.
When cards are installed, the red LED on the faceplate flashes
as a self-test runs. If the self-test is completed successfully, the
card is automatically enabled (if it is configured in software) and
the LED goes out. If the self-test fails, the LED lights steadily
and remains lit.
Software-enable the card by entering: ENLC l s c
When the process is complete, a system response appears.
To end the program, enter four asterisks (****).
Action
Software-disable the card with the following command:
LD 54
Unhook the locking devices on the card. Pull it out of the card
cage.
Insert the replacement card into the vacant slot and hook the
locking devices.
After you install cards, the red LED on the faceplate flashes as a
self-test runs. If the self-test succeeds, the card is automatically
enabled (if it is configured in software) and the LED turns off. If
the self-test fails, the LED lights steadily and remains lit.
Software-enable the card by entering: ENLC l s c
When the process is complete, a system response appears.
Nortel Communication Server 1000
Communication Server 1000E Maintenance
NN43041-700 04.01 4 June 2010
Copyright © 2004-2010 Nortel Networks. All Rights Reserved.
--End--
DISC l s c
