Access through an SDI system terminal
Send maintenance commands and receive system messages by
accessing the Call Server, through an RS-232 device, such as a VDT or
TTY.
On the Call Server, the device can be connected through the Terminal
Server or through a Com port. If the RS-232 device is connected
directly to the Call Server Com port, a separate terminal is required to
communicate with each Call Server in the Core.
When you access the system through a system terminal, a login procedure
is required. All system passwords are initially set to"0000". Change
passwords in the Configuration Record in LD 17. If a system reload
(sysload) occurs before the new password is saved in a data dump, the
last active password remains valid.
Accessing the system from an SDI system terminal
To access the system from an SDI system terminal, follow the steps in
Procedure 1 "Accessing the system from an SDI system terminal" (page
23).
Procedure 1
Accessing the system from an SDI system terminal
Step Action
1 Connect port 0 of the SDI cable to call server and terminal
server.
Route RS232 cable to the call server and the other cable to
terminal server.
2 Press Return.
a If the response is OVL111 nn IDLE or OVL111 nn BKGD, you
b If the response is OVL000 > , you are already logged into the
3 Enter LOGI ADMIN1 and press Return.
The normal response is PASS?. If there is any other response,
see Software Input/Output Reference – Maintenance
NN43001-711.
4 Enter either the level 1 or level 2 password and press Return. If
the password is correct, the system responds with the prompt >.
5 Enter LD xx, where xx represents the number of the program.
6 Perform tasks.
Communication Server 1000E Maintenance
Copyright © 2004-2010 Nortel Networks. All Rights Reserved.
are ready to log into the system. Go to
system. Go to step 4.
Responses vary with different Background Terminal
packages.
Nortel Communication Server 1000
NN43041-700 04.01 4 June 2010
Accessing the system 23
step 2.
