VLT® Decentral Drive FCD 302
Operating Guide

1 Introduction

1.1 Purpose of this Operating Guide

This Operating Guide provides information for safe installation and commissioning of the AC drive. It is intended for use by qualified
personnel. Read and follow the instructions to use the drive safely and professionally. Pay particular attention to the safety instruc-
tions and general warnings. Always keep this Operating Guide available with the drive.

1.2 Additional Resources

Other resources are available to understand advanced drive functions and programming.
• The VLT® Decentral Drive FCD 302 Design Guide provides detailed information about capabilities and functionality to design
motor control systems.
• The VLT® AutomationDrive FC 301/302 Programming Guide provides greater detail on working with parameters and many ap-
plication examples.
• Instructions for operation with optional equipment.
Supplementary publications and manuals are available at www.danfoss.com.

1.3 Manual and Software Version

This manual is regularly reviewed and updated. All suggestions for improvement are welcome.
Table 1: Manual and Software Version
Edition
AQ267036816112, version 0101

1.4 Product Overview

1.4.1 Intended Use

The drive is an electronic motor controller intended for:
• Regulation of motor speed in response to system feedback or to remote commands from external controllers. A power-drive
system consists of the drive, the motor, and equipment driven by the motor.
• System and motor status surveillance.
The drive can also be used for motor protection.
Depending on the configuration, the drive can be used in standalone applications or form part of a larger appliance or installation.
The VLT® Decentral Drive FCD 302 is designed for decentral mounting, for example, in the food and beverage industry, or for other
material handling applications. With the FCD 302 , it is possible to reduce costs by placing the power electronics decentrally. Central
panels are then rendered obsolete, saving cost, space, and effort for installation and wiring. The basic design is service-friendly with
a pluggable electronic part and a flexible and spacious wiring box. It is easy to change electronics without the need for rewiring.
Installation environment: The drive is allowed for use in residential, industrial, and commercial environments in accordance with
local laws and standards.
RADIO INTERFERENCE
In a residential environment, this product can cause radio interference, in which case supplementary mitigation measures can be
required.
-
Take the necessary precautions.
Foreseeable misuse
Do not use the drive in applications which are non-compliant with specified operating conditions and environments.
Ensure compliance with the conditions specified in
6 | Danfoss A/S © | 2020.07
Remarks
Update to latest software with control card update in April 2020
N O T I C E
7.4.1 Environment.
Introduction
Software version
8.5X
AQ267036816112EN-000101 / 130R0208
