VLT® Decentral Drive FCD 302
Operating Guide
431.5 mm (16.98 in)
380 mm (14.96 in)
32 mm
(1.25 in)
415 mm (16.33 in)
449.5 mm (17.69 in)
Illustration 31: Cable Entries and Hole Sizes (Large Unit)
Table 23: Mechanical Dimensions
Motor side
Control side
Mains side
1 Also used for 4xM12/6xM12 sensor/actuator sockets.
68 | Danfoss A/S © | 2020.07
6.5 mm
(0.25 in)
Ø13 mm
(0,51 in)
1xM20, 1xM25
2xM20, 9xM16
(1)
2xM25
Specifications
AQ267036816112EN-000101 / 130R0208
