VLT® Decentral Drive FCD 302
Operating Guide
Name Color
Bus NS2 Only relevant if optional fieldbus is present. See fieldbus-dedicated manuals for
specific information.

6.4 Status Display

When the drive is in Status mode, status messages are generated automatically and appear in the bottom line of the display, see
Illustration 26.
Status
799RPM
Auto Remote
Hand Local
Off
1
2
3
Illustration 26: Status Display
1 Operating mode (see
2 Reference site (see

6.5 Status Message Definitions

See Table 17 to Table 19 for definitions of the status messages.
Table 17: Operating Mode
Off
The drive does not react to any control signal until [Auto On] or [Hand On] is pressed.
The drive is controlled from the control terminals and/or the serial communication.
Auto On
Hand On The drive is controlled by the navigation keys on the LCP. Stop commands, reset, reversing, DC brake, and other sig-
nals applied to the control terminals override local control.
Table 18: Reference Site
Remote The speed reference is given from external signals, serial communication, or internal preset references.
Local
The drive uses [Hand On] control or reference values from the LCP.
Table 19: Operation Status
AC Brake
[2] AC brake is selected in parameter 2-10 Brake Function. The AC brake overmagnetizes the motor to achieve a
controlled slow down.
AMA finish AMA was carried out successfully.
OK
AMA ready AMA is ready to start. Press [Hand On] to start.
42 | Danfoss A/S © | 2020.07
Status
1(1)
7.83A 36.4kW
0.000
53.2%
Ramping
Stop
Running
Jogging
.
.
.
Standby
Table 17)
Table 18)
Indication, frontal LEDs
Bus Network Status 2
3 Operation status (see
AQ267036816112EN-000101 / 130R0208
Maintenance, Diagnostics and
Troubleshooting
Table 19)
