VLT® Decentral Drive FCD 302
Operating Guide
Table 25: Parameter 1-20 Motor Power [kW]
Range
Size re- [0.09 -
lated* 3000.00 kW]
Table 26: Parameter 1-22 Motor Voltage
Range
Size related* [10 - 1000 V]
Table 27: Parameter 1-23 Motor Frequency
Range Function
Size re- [20 -
lated* 1000 Hz]
From software version 6.72 onwards, the output frequency of the drive is limited to 590 Hz.
Select the motor frequency value form the motor nameplate data. If a value other than 50 Hz or 60 Hz is
selected, adapt the load-independent settings in parameter 1-50 Motor Magnetization at Zero Speed to
parameter 1-53 Model Shift Frequency. For 87 Hz, adapt parameter 4-13 Motor Speed High Limit [RPM] and
parameter 3-03 Maximum Reference.
Table 28: Parameter 1-24 Motor Current
Range
Size rela- [0.10 -
ted* 10000.00 A]
Table 29: Parameter 1-25 Motor Nominal Speed
Range
Size rela- [100 -
ted* 60000 RPM]
Table 30: Parameter 5-12 Terminal 27 Digital Input
Option
Danfoss A/S © | 2020.07
Function
This parameter cannot be adjusted while the motor is running.
Enter the nominal motor power in kW according to the motor nameplate data. The default value
corresponds to the nominal rated output of the drive. This parameter is visible in the LCP if parame-
ter 0-03 Regional Settings is set to [0] International.
Function
Enter the nominal motor voltage according to the motor nameplate data. The default value corre-
sponds to the nominal rated output of the drive.
Function
This parameter cannot be adjusted while the motor is running.
Enter the nominal motor current value from the motor nameplate data. The data is used for calcu-
lating motor torque, motor thermal protection, and so on.
Function
This parameter cannot be adjusted while the motor is running.
Enter the nominal motor speed value from the motor nameplate data. The data is used for calcu-
lating automatic motor compensations.
Function
Select the function from the available digital input range.
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AQ267036816112EN-000101 / 130R0208 | 71
