VLT® Decentral Drive FCD 302
Operating Guide
Option
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Setup select bit 0
[24] Setup select bit 1
[28] Catch up
[29] Slow down
[32] Pulse input
[34] Ramp bit 0
[35] Ramp bit 1
[36] Mains failure inverse
[55] DigiPot increase
[56] DigiPot decrease
[57] DigiPot clear
