VLT® Decentral Drive FCD 302
Operating Guide
Table 11: Legend to Area A, Display Area
Callout Parameter
1
Parameter 0-20 Display Line 1.1 Small
2 Parameter 0-21 Display Line 1.2 Small
3 Parameter 0-22 Display Line 1.3 Small
4
Parameter 0-23 Display Line 2 Large
5
Parameter 0-24 Display Line 3 Large
Area B: Display menu keys
Menu keys are used for menu access for parameter set-up, toggling through status display modes during normal operation, and
viewing fault log data.
Table 12: Legend to Area B, Display Menu Keys
Callout Key Function
6 Status Shows operational information.
7 Quick Menu Allows access to programming parameters for initial setup instructions and many detailed application
instructions.
8 Main Menu Allows access to all programming parameters.
9 Alarm Log Shows a list of current warnings, the last 10 alarms, and the maintenance log.
Area C: Navigation keys and indicator lights (LEDs)
Navigation keys are used for programming functions and moving the display cursor. The navigation keys also provide speed control
in local (hand) operation. There are also 3 drive status indicator lights in this area.
Table 13: Legend to Area C, Navigation Keys
Callout Key
10 Back
11 Cancel
12 Info
13 Navigation keys
14 OK
Table 14: Legend to Area C, Indicator Lights (LEDs)
Callout Indicator Light
15 ON Green
16 WARN Yellow
17 ALARM Red
Area D: Operation keys and reset
Operation keys are a the bottom of the LCP.
36 | Danfoss A/S © | 2020.07
Function
Reverts to the previous step or list in the menu structure.
Cancels the last change or command as long as the display mode has not changed.
Press for a definition of the function being shown.
Press to move between items in the menu.
Press to access parameter groups or to enable a choice.
Function
The ON light activates when the drive receives power from mains voltage, a DC bus terminal, or an
external 24 V DC supply.
When warning conditions are met, the yellow WARN light comes on and text appears in the dis-
play area identifying the problem.
A fault condition causes the red alarm light to flash and an alarm text is shown.
Commissioning
Default setting
[1617] Speed [RPM]
[1614] Motor Current
[1610] Power [kW]
[1613] Frequency
[1602] Reference %
AQ267036816112EN-000101 / 130R0208
