5.6 Bearing lubrication

5.6 Bearing lubrication
WARNING:
Risk of explosive hazard and premature failure from sparks and heat generation. Ensure
bearings are properly lubricated prior to startup.
Pumps are shipped without oil. You must lubricate oil-lubricated bearings at the job site.
Grease-lubricated bearings are lubricated at the factory.
The bearing manufacturer fills greased-for-life bearings with grease and seals them at the factory. You do
not need to lubricate or seal these bearings.

5.6.1 Lubricating oil requirements

Oil quality requirements
Use a high-quality turbine oil with rust and oxidation inhibitors.
Lubricating oil type
Symbol
Kinematic viscosity at 40°C | 104°F
Flash point (Cleveland)
Setting point (Pourpoint)
Application temperature
(Contact your ITT representative to determine a suitable
type of lubrication if ambient temperatures are below
-10°C | 14°F.
Oil quantity requirements
Bearing frame size
24 i-FRAME
32 i-FRAME
42 i-FRAME
48 i-FRAME

5.6.2 Lubricate the bearings with oil

WARNING:
Risk of explosive hazard and premature failure from sparks and heat generation. Ensure
bearings are properly lubricated prior to startup.
NOTICE:
The pump is not filled with oil when delivered. Fill with oil before operating the pump.
• Determine which procedure to use in order to fill the bearing frame with oil:
50 Model ICO i-FRAME, ICOH i-FRAME Installation, Operation, and Maintenance Manual
• CLP46
• DIN 51517
• HD 20W/20 SAE
DIN 51502
2
46 ±4 mm /sec |
2
0.0713 ±0.006 in. /sec
175°C | 347°F
-15°C | 5°F
Higher than permitted bearing temperature
Oil quantity in liters | quarts
0.5 | 0.53
1.1 | 1.16
1.5 | 1.58
2.1 | 2.21
