Figure 27: Coupling hub removal
6.6.7 Remove the impeller
WARNING:
•
Risk of severe physical injury or death from explosion of trapped liquid. Never use heat to
remove parts unless explicitly stated in this manual.
•
Risk of serious physical injury or equipment damage. Pump and components are heavy.
Ensure all equipment is properly supported while working. Wear appropriate Personal
Protective Equipment (PPE, such as steel-toed shoes, gloves, etc.) at all times.
CAUTION:
Risk of physical injury from sharp edges. Wear heavy work gloves when handling impellers.
1.
the axial clearance (a) between the impeller and the casing cover .
Figure 28: Back clearance check
Model ICO i-FRAME, ICOH i-FRAME Installation, Operation, and Maintenance Manual
6.6 Disassembly
71
