3.3 Nameplate information
Pump nameplate
Figure 3: Pump nameplate
Nameplate Field
S/N
MODEL
SIZE
STD DIM
HYDRO PRESS
FLOW
RPM
MAX DESIGN WORKING PRESS
HEAD
MATL
IMP DIA
CONT/ITEM NO
MAX DIA
Model ICO i-FRAME, ICOH i-FRAME Installation, Operation, and Maintenance Manual
Explanation
Serial number of the pump
Pump Model
Size of Pump
ANSI Std designation – Not applicable ISO Pumps
Pump Test Pressure in kPag
Rated pump flow in cubic metres per hour
Rated pump speed in revolutions per minute
Maximum Design pressure in kPag at rated temperature in degrees
Centigrade
Rated pump head in metres
Material of which the pump is constructed
Impeller diameter fitted
Contract or tag number
Maximum impeller diameter
3.3 Nameplate information
17
