Install casing cover (161) on frame adapter (344) - ensure proper orientation with flush tap accessi-
ble through top of frame adapter (344).
5.
Slide the cartridge seal into the seal chamber and secure using the four studs and nuts.
6.
Complete Pump Assembly before tightening seal rotating section set screws and removing center-
ing clips.
6.8.3.4 Seal the shaft with a conventional inside-component mechanical
seal
1.
Before proceeding with seal installation, complete Steps 1-29 on
od and installation on page
2.
Measure distance from the shaft sleeve face (524) to rotating component seat in casing cover (161)
and record this value as "L1" - see
3.
Consult seal instructions for component L
Offset) - See
4.
Install Stationary seal component in casing cover (161) using appropriate O-ring lubricant.
5.
Remove the shaft sleeve (524) and rotating component assembly from the shaft - Leave shims
(525) on the shaft.
NOTICE:
Check sleeve to ensure no shims were retained after removal.
6.
Slide rotating seal component on shaft sleeve (524) using appropriate O-ring lubricant.
7.
Move the rotating component down the shaft sleeve to the determined seal offset (L1-L
Offset).
8.
Tighten set screws per the seal manufacturers guidelines.
9.
Replace shaft sleeve / seal assembly on shaft.
Model ICO i-FRAME, ICOH i-FRAME Installation, Operation, and Maintenance Manual
85.
Figure 50: Initial seal measurement on page
1.
Sleeve face
2.
Seal rotating component
3.
Seal instructions "L
4.
Initial measurement "L1"
Figure 50: Initial seal measure-
ment
Figure 50: Initial seal measurement on page
"
1K
dimensions and subtract L
1K
91.
6.8 Reassembly
6.8.3.1 Shim measurement meth-
91.
1.
Sleeve face
2.
Seal rotating component
3.
Set screw
4.
Seal offset = L1 - L
Figure 51: Setting seal at deter-
mined value
from L1 (L1-L
1K
1K
1K
1K
= Seal
= Seal
91
