Prohib- ited methods include any modification to the equipment or use of parts not provided by ITT. If there is any uncertainty regarding the appropriate use of the equipment, please contact an ITT representative before proceeding.
1.1 Safety 1.1.1 Safety terminology and symbols About safety messages It is extremely important that you read, understand, and follow the safety messages and regulations carefully before handling the product. They are published to help prevent these hazards: • Personal accidents and health problems •...
WARNING: If the product has been contaminated in any way, such as from toxic chemicals or nuclear radi- ation, do NOT send the product to ITT until it has been properly decontaminated and advise ITT of these conditions before returning.
Page 7
1.1 Safety • Make sure that all safety guards are in place and secure. • Recognize the site emergency exits, eye wash stations, emergency showers and toilets. • Allow all system and pump components to cool before you handle them. •...
ITT disclaims all responsibility for work done by untrained and unauthorized personnel. These are the personnel requirements for Ex-approved products in potentially explosive atmospheres: • All work on the product must be carried out by certified electricians and ITT-authorized mechan- ics. Special rules apply to installations in explosive atmospheres. •...
Use of equipment unsuitable for the environment can pose risks of ignition and/or explosion. Ensure the pump driver and all other auxiliary components meet the required area classifica- tion at the site. If they are not compatible, do not operate the equipment and contact an ITT representative before proceeding.
All service and repair work is done by ITT-authorized personnel. • Genuine ITT parts are used. • Only Ex-approved spare parts and accessories authorized by ITT are used in Ex-approved prod- ucts. Limitations The warranty does not cover faults caused by these situations: •...
Dispose of all packing materials in accordance with local regulations. Inspect the unit to determine if any parts have been damaged or are missing. Contact your ITT representative if anything is out of order. Pump should be placed in upright position only.
2.4 Pump storage requirements Examples Figure 1: Example of proper lifting method using lifting lugs 2.4 Pump storage requirements Requirements Submersible units require proper preparation for storage and regular maintenance during storage. The unit is considered in storage when it has been delivered to the job site and is awaiting installation. For specific requirements for storing motors, gearheads, engines, panels, sealing plans and other auxil- iaries, contact the equipment manufacturer.
15 minutes every two weeks. 2.5 Preservation and Storage ITT Goulds Pump Division's normal domestic shipping and storage preparation is suitable for protecting the pump during shipment in covered trucks. Although this is a submersible pump, storage in a clean, dry area will help preserve the paint and prevent corrosion.
NOTICE: The motor is rated for full horsepower with liquid temperatures of 104°F (40°C) or lower, unless noted otherwise on nameplate or ITT documentation. 3.4 Install the pump Make sure the lifting device is securely fastened to the motor lugs or hooks so the unit will not be dropped when it is lowered into the sump.
3.5 Slide rail system (optional) Position item #787G, sump flange adapter, as shown in section Y-Y and secure to base upright us- ing items #372K. Apply gasket adhesive to item #360W and place in section Y-Y and secure to base upright. Insert short-threaded end of stubs, items #787U, through base uprights and into the top two holes of the sump flange adapter, item #787G.
3.5 Slide rail system (optional) Remove items #371G and #357A and position lift cable loop between lifting brackets. Apply Loctite 271 and reinsert item #371G, hex head cap screw, through cable and lifting brackets and thread heavy hex nut, item #357A, and item #415A, jam nut, onto item #371G. Check cable clamps.. 3.5.4 Install the slide rail Refer to drawing B1-445153SLR and B2-445153SLR With anchor bolts in position, lower the base, item #787A, onto a flat, clean foundation and tighten...
Page 17
3.5 Slide rail system (optional) Figure 2: Slide rail system (optional) JCU Installation, Operation, and Maintenance Manual...
Page 18
3.5 Slide rail system (optional) Figure 3: Slide rail system (optional) JCU Installation, Operation, and Maintenance Manual...
4 Commissioning, Startup, Operation, and Shutdown 4 Commissioning, Startup, Operation, and Shutdown 4.1 Start the pump The most important concern is the prevention of motor overloading. Refer to the motor nameplate for full load ampere rating of the motor. Install an ammeter on the motor leads and check the motor draw immediately after the unit is start- NOTICE: A lower than expected current draw with a 3-phase motor may be an indication of incorrect ro- tation.
5 Maintenance 5 Maintenance 5.1 Maintenance 5.1.1 Maintenance - O-ring, pump flange to slide rail base flange Whenever the pump is removed from the sump using the slide rail system, the pump flange to slide rail base flange O-ring should be inspected for wear. If it does not appear to be in good condition, a replace- ment O-ring should be installed after the groove has been cleaned and dried so the adhesive will bond to the metal and rubber.
5.3 Pre-assembly CAUTION: • Avoid injury. Worn pump components can have sharp edges. Wear appropriate gloves while handling these parts. 5.2.2 Disassemble the pump Disconnect all electrical service. Mark leads for reassembly. Remove cap screws 370E that fasten suction cover to casing. Remove cover and suction cover lin- Remove impeller cap screw 370C.
5.4 Reassembly Inspect the casing for cracks and excessive wear or pitting. Thoroughly clean gasket surfaces and align- ment fits in order to remove rust and debris. Repair or replace the casing if you notice any of these conditions: • Localized wear or grooving that is greater than 3.2 mm | 1/8 in.
Page 23
5.4 Reassembly Install the O-ring (412F) around the liner lip and install suction cover with cap screws (370E) and washers (528K). Check for free rotation by turning impeller clockwise by hand with wrench on im- peller screw. 12. When connecting electrical service, make sure polarity is correct to give counterclockwise rotation when looking into the suction opening.
Page 24
5.4 Reassembly Table 2: Impeller Shim Thickness Impeller Diameter (inches) Measure Clearance Minus Shim Thickness (in- ches) up to 11 .010 to .015 11 to 14 .015 to .020 over 14 .020 to .025 NOTICE: • For 360TY with 320TY mounting flange motors only, delete impeller washer (199) and impeller screw (370C) and replace with impeller nut (304) of 316SS for all pump con- structions.
6 Troubleshooting 6 Troubleshooting 6.1 Troubleshooting Symptom Cause Remedy Insufficient or no dis- Speed too low (usually due to low volt- Verify proper voltage charge age) System head too high Verify discharge pressure Insufficient NPSH or submergence Verify liquid level is above minimum required Wear of pump parts Review pump parts for wear Wrong direction of rotation...
