1 x AX96410: 1 PCIex16 + 3 PCIex4 or
1 x AX96411: 1 PCIex16 + 1 PCIex4 + 2PCI
Note: The maximum power rating for expansion slots at 60
the following value:
The maximum loading of +3.3V+5V+12V<150W
Note: 12V maximum loading is 12A(144W).
Note: The system power rating may thus be changed base on differing combinations of
attached devices.
 Drive Capacity
 Supports two 2.5" HDD driver bays (SSD/HDD 7 or 9.5mm height)
Note: Since Gen. 2 SSD with JMicron controller has a compatibility issue with
Intel H310 PCH, it is strongly recommended to use Gen. 3 SSD on the
IPC962 Series.
 Power Input

24VDC (uMin=19V/uMax=30V) with phoenix power plug
Note: Please fix the system power input in 24Vdc when plugging an add-on card.
 Operating Temperature
Proc No
Generation
Coffee Lake-S
i9-9900
refresh
Coffee Lake-S
i5-9600
refresh
Coffee Lake-S
i5-9500F
refresh
Coffee Lake-S
i5-9500E
refresh
Coffee Lake-S
i5-9500
refresh
Coffee Lake-S
i5-9400F
refresh
Coffee Lake-S
i5-9400
refresh
Coffee Lake-S
i3-9100F
refresh
Coffee Lake-S
i3-9100
refresh
Coffee Lake-S
i3-9320
refresh
Introduction
IPC960/IPC962/IPC964-525 Series User's Manual
WATT Core Thread
65 8 16
65 6 6
65 6 6
65 6 6
65 6 6
65 6 6
65 6 6
65 4 4
65 4 4
62 4 4
℃
cannot exceed
Operating
Remark
Temperature
-10℃-50℃ *
-10℃-50℃ *
-10℃-50℃ *
-10℃-50℃ *
-10℃-50℃ *
-10℃-50℃ *
-10℃-50℃ *
-10℃-50℃
-10℃-50℃
-10℃-50℃
Base
frequency
3.1 GHz
3.1 GHz
3.0 GHz
3.0 GHz
3.0 GHz
2.9 GHz
2.9 GHz
3.6 GHz
3.6 GHz
3.7 GHz
