OptiView T1/E1 and DS3/E3 WAN Analyzers
The Remote User Interface
Table 2. Front Page Main Buttons (continued)
Button Description
Displays the leading four transmitting hosts
(devices) on the WAN link that the analyzer is
connected to. This measurement is based on
the octet count of IPv4 packets sent by all
hosts using the WAN link or by a selected DLCI
(Frame Relay only).
Click this button to display detailed
Top Hosts
information on the leading 50 hosts.
Displays the number of devices by type that
the analyzer discovered on the entire WAN
link or on a selected DLCI (Frame Relay only).
Specific address and domain names are given.
Device discovery is periodically cycled and
updated.
Devices
Click this button to view details for each
discovered device.
Displays the leading four TCP or UDP
applications detected by the analyzer on the
entire WAN link or on a selected DLCI (Frame
Relay only). These four applications are
generating the highest combined output of
octets for both directions (DTE for the
outbound direction and DCE for the inbound
direction).
Top Applications
Click this button to view detailed information
on the leading 50 applications.
39
