Connecting the Analyzer's Ethernet MANAGEMENT Port to the LAN

You need to connect the analyzer's Ethernet
LAN. Complete the following:
1. Using the supplied (or your own) CAT5 patch cable, connect one
end to the
front panel (Figure 2 or 3).
2. Connect the other end of the cable to the 10/100 Ethernet network
that matches the IP subnet that you statically configured for the
analyzer.

Connecting the PC to the Network

The PC that remotely controls the analyzer must be connected to the
network. The connection diagrams in Figures 10 and 11 illustrate the
two ways a PC can be connected.
In Figure 10, the PC with the remote user interface software installed is
connected to the same Ethernet network (broadcast domain) that the
analyzer's
MANAGEMENT
port, which is located on the analyzer's
MANAGEMENT
port is connected to.
Switch or Hub
Figure 10.
MANAGEMENT
OptiView T1/E1 and DS3/E3 WAN Analyzers
MANAGEMENT
Port to LAN Connection
Setting Up the Analyzer
port to the
awu08f.eps
