Setting Automatic Operation Options

The cabinet allows you to configure it to activate functions automatically when the
sash is opened or closed.
The first screen gives you the option of activating the
blower; if you want the cabinet blower to start every
time you raise the sash, select
[OK/Mute]. If Blower Off
must be manually started from the keypad. When
[OK/Mute] is pressed, the next configuration screen
will appear.
If you want the cabinet lights to turn on every time
you raise the sash, select
[OK/Mute]. If Light Off
be manually turned on from the keypad. When
[OK/Mute] is pressed, the next configuration screen
will appear if your cabinet is configured for a UV
lamp.
If your Cabinet is configured for a UV light, you will
see Fig. 5-7j and 5-7k. If you want the UV lamp to
turn on every time the sash is closed, select
On, and press [OK/Mute]. If
the UV light will not turn on when the sash is closed.
When [OK/Mute] is pressed, the final configuration
screen will appear.
Whether the UV Light is initiated from the
Light] button on the keypad, or automatically
initiated upon closing of the sash, this screen
controls the time the UV lamp will remain on.
Select the length of time desired, press
[OK/Mute].
5: Using The Cabinet
Blower On, and then
is selected, the blower
Light On, and then
is selected, the lights must
UV Light Off is selected,
[UV
OPEN SASH:
START
BLOWER
OPEN SASH:
LIGHT ON
UV Light
CLOSE SASH:
UV LIGHT ON
10 30
0
Figure 5-7g
Figure 5-7i
Figure 5-7j
Figure 5-7k
60 120
40
