5: Using The Cabinet
Navigating the Cabinet Menu Screens
Keypad button presses are shown as
[blue with
brackets]. Menu screen
selections are shown as
green
italics.
NOTE: Pressing the appropriate keypad button will override Automatic Operation
mode functions (such as SmartStart and NightSmart).
To access the main menu, press the
[MENU]
button. The display panel will
change to the main menu. To select from the various menu options press the
[UP]
or
[DOWN]
buttons until the selected option is highlighted. Press
[OK/MUTE]
to
accept that option, or press
[MENU]
to return to the previous menu level.
Figure 5-7a
[MENU]
Figure 5-7b
Configuration
Settings
Tools
37
