Electrical Requirements

The cabinet models have the following electrical requirements:
Model Number
3034xxx01
3034xxx21
3034xxx-11, 31, 41, 51, 61, 71
3036xxx01
3036xxx21
3036xxx-11, 31, 41, 51, 61, 71
1 Electrical Requirements, 'V' = VAC (Voltage with alternating current), 'A' = Amperes
A dedicated outlet with an appropriate circuit breaker should be located as
close as possible to the right rear side of the cabinet, at a height even with,
or higher than, the top of the bench or stand. Consult your local electrical
codes for properly rated circuit breakers. For safe operation the dedicated
outlet must provide the protective earthing ground connection to the
cabinet.
On 100 and 115 VAC models, both internal electrical outlets are protected by a
ground fault interrupter circuit (GFIC). Labconco does not recommend plugging
the cabinet into a GFIC outlet.
Electrical outlets in the cabinet are restricted to 5 amps (115 Volt
models) or 2 amps (230 Volt models) maximum current.
Les prises électriques dans l'armoire sont limitées à 5 ampères
(modèles 115 volts) ou 2 ampères (modèles 230 volts) courant
maximum.
Do not use any detachable power cord that is not adequately rated for the
unit.
Ne pas utliser un fil électrique amovible qui n'est pas du tension
nominale de l'appareil.
2: Prerequisites
Typical Operating
Current (Amps)
3 A
3 A
1.5 A
5 A
5 A
2.5 A
Table 2-1
Electrical Circuit
1
Requirements
115 V, 60 Hz, 12 A
100 V, 50/60 Hz, 12 A
230 V, 50/60 Hz, 6 A
115 V, 60 Hz, 12 A
100 V, 50/60 Hz, 12 A
230 V, 50/60 Hz, 6 A
