Appendix B: Dimensions

All dimensions are shown in inches.
C
8.8
72.6
21.7 Max Loading
Exhaust duct stub sized
for 10 inch outside
diameter duct connection
B
A
Power Cord Connection
Width A
4' 54.3
6' 78.3
61.7
B-1
B C
48.5 17.2
72.5 28.9
Power Cord
Connection
25.7
17.6
31.2
60
29.2
